BRAVOPRODIGY 4"/102 PORTABLE TILE SAW / 4" WET TILE SAWTC104

  • Blade cooling water reservoir is removable for easy cleaning
  • Large durable cutting table for support of large tiles
  • Tilt-up cutting table for precision 15, 30 and 45 degree mitre cuts
  • Adjustable angle and rip guides for accurate production cuts
  • Splash guard keeps dust, debris and water spray to a minimum
  • Automatic thermal overload protection prevents tile saw from overheating
Inquery
PREVPREV
BACK
NEXTNEXT
  • Feature
  • Specifications

Model TC104
VOLTAGE  230V/50HZ 120V/60HZ
MOTOR  185W
RPM  3000  3600
BLADE CAPACITY  102mm  4"
ARBOR  16mm  5/8"
STRAIGHT CUT  UNLIMITED
DIAGONAL CUT  UNLIMITED
CUTTING DEPTH  15.8mm  5/8"
CUTTING DEPTH AT 45°  10mm  3/8"
ANGLE CUT  22.5°, 45°
BEVEL CUT  22.5°, 30°, 45°
